Reducing Tee

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 20mm to 630mm in different pressure ratings ranging from PN 4 to PN 16kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE
SIZE
D D
B MIN.
MIN MAX MIN MIN
PVFRT22520006 225 x 200 225.3 225.7 200.3 200.6 338
PVFRT25022506 250 X 225 250.4 250.8 225.3 225.7 375
PVFRT28025006 280 X 250 280.4 280.9 250.4 250.8 420
PVFRT31528006 315 X 280 315.4 316 280.4 280.9 473
PVFRT35531506 355 X 315 355.4 356 315.4 316 521
PVFRT40035506 400 X 355 400.4 401 355.4 356 586
PVFRT45040006 450 X 400 450.4 451 400.4 401 659
PVFRT50045006 500 X 450 500.4 501 450.4 451 731
Note :
• All dimensions are in mm
• All fabricated fittings are available in different pressure classes up to PN 20 kg/cm2 as per
ISO : 1452. Fittings in other standard and not covered above are also made available on request.
