Quick-fix Coupler

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 63mm to 500mm in different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE ND B MIN. L MIN.
PVFCQ06310 63 250 107
PVFCQ07510 75 250 112
PVFCQ09010 90 250 118
PVFCQ11010 110 250 127
PVFCQ12510 125 250 133
PVFCQ14010 140 270 139
PVFCQ16010 160 270 146
PVFCQ18010 180 290 156
PVFCQ20010 200 320 164
PVFCQ22510 225 320 175
PVFCQ25010 250 350 185
PVFCQ28010 280 350 198
PVFCQ31510 315 430 215
PVFCQ35510 355 430 230
PVFCQ40010 400 450 242
PVFCQ50010 500 550 279
Note:
• All dimensions are in mm
• All fabricated fittings are available in different pressure classes up to PN 20 kg/cm2 as per ISO : 1452. Fittings in other standard and not covered above are also made available on request.
