PVC Solvent Cement Coupler

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 20mm to 630mm in different pressure ratings ranging from PN 4 to PN 16kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

Code D B L   Code D B L
PVFCS020x10 20 20 16.0 PVFCS160x10 160 45 86.0
PVFCS025x10 25 20 19.0 PVFCS180x10 180 45 96.0
PVFCS032x10 32 20 22.0 PVFCS200x10 200 45 106.0
PVFCS040x10 40 20 26.0 PVFCS225x10 225 55 118.0
PVFCS050x10 50 20 31.0 PVFCS280x10 280 55 146.0
PVFCS063x10 63 20 37.5 PVFCS315x10 315 55 163.5
PVFCS075x10 75 20 43.5 PVFCS355x10 355 65 183.5
PVFCS090x10 90 35 51.0 PVFCS400x10 400 65 206.0
PVFCS110x10 110 35 61.0 PVFCS450x10 450 65 231.0
PVFCS125x10 125 35 68.5 PVFCS500x10 500 65 256.0
PVFCS140x10 140 45 76.0 PVFCS560x10 560 75 286.0

Note:
• All dimensions are in mm.
• All fabricated fittings are available in 10 kg/cm² pressure rating. Please specify other pressure ratings as per the requirement viz. 04, 06, 08, 12.5 kg/cm². eg. for PVC Solvent Cement Coupler 20mm size and 6 kg/cm² pressure rating, specify code as PVFCS020X06.
