Quick-Fix Repair Coupler

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 63mm to 500mm in different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE ND L MIN.
PVFRQC063X10 63 540.0
PVFRQC075X10 75 560.0
PVFRQC090X10 90 580.0
PVFRQC110X10 110 605.0
PVFRQC125X10 125 620.0
PVFRQC140X10 140 640.0
PVFRQC160X10 160 670.0
PVFRQC180X10 180 691.0
PVFRQC200X10 200 715.0
PVFRQC225X10 225 748.0
PVFRQC250X10 250 775.0
PVFRQC280X10 280 825.0
PVFRQC315X10 315 859.0
PVFRQC355X10 355 904.0
PVFRQC400X10 400 943.0
PVFRQC500X10 500 1057.0
Note :
• All dimensions are in mm • All fabricated fittings are available in different pressure classes up to PN 20 kg/cm2 as per ISO : 1452. Fittings in other standard and not covered above are also made available on request.
