Quick-fix Double socket Bend 60°

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 63mm to 500mm in different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

Code ND size
Y L R
PVFBQDS60063X10 63 149 107 189
PVFBQDS60075X10 75 177 112 225
PVFBQDS60090X10 90 212 118 270
PVFBQDS60110X10 110 259 127 330
PVFBQDS60125X10 125 295 133 375
PVFBQDS60140X10 140 330 139 420
PVFBQDS60160X10 160 377 146 480
PVFBQDS60180X10 180 424 156 540
PVFBQDS60200X10 200 471 164 600
PVFBQDS60225X10 225 530 175 675
PVFBQDS60250X10 250 589 185 750
PVFBQDS60280X10 280 660 198 840
PVFBQDS60315X10 315 742 215 945
PVFBQDS60355X10 355 837 229 1065
PVFBQDS60400X10 400 842 242 1200
PVFBQDS60450X10 450 1060 259 1350
PVFBQDS60500X10 500 1178 279 1500
Note :
• All dimensions are in mm.
•Also we can provide Double side socket 6,8,12.5 kg
