PVC Quick-Fix Double Socket Bend 60°

All Products..

PVC Pipes

download pdf file

PVC Quick-Fix Double Socket Bend 60°

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 63mm to 500mm in different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

Code D Y
L R
PVBFQ60063x10 63 198 240 189
PVBFQ60075x10 75 236 246 225
PVBFQ60090x10 90 283 266 270
PVBFQ60110x10 110 346 270 330
PVBFQ60140x10 140 440 316 420
PVBFQ60160x10 160 503 316 480
PVBFQ60180x10 180 566 346 540
PVBFQ60200x10 200 629 370 600
PVBFQ60225x10 225 760 390 675
PVBFQ60250x10 250 786 446 750
PVBFQ60280x10 280 880 450 840
PVBFQ60315x10 315 990 450 945
PVBFQ60355x10 355 1115 460 1065
PVBFQ60400x10 400 1256 500 1200

Note :
• All dimensions are in mm.
• All fabricated fittings are available in 10 kg/cm² pressure rating. Please specify other pressure ratings as per the requirement viz. 04, 06, 08, 12.5 kg/cm²
• Other fittings / sizes are available on demand.
