Quick-Fix Bend 45°

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 63mm to 500mm in different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE ND Y MIN. L MIN. R MIN.
PVFBQ45063X10 63 149.0 133 189
PVFBQ45075X10 75 177.0 142.5 225
PVFBQ45090X10 90 212.0 157 270
PVFBQ45110X10 110 259.0 176 330
PVFBQ45125X10 125 295.0 189.5 375
PVFBQ45140X10 140 330.0 203 420
PVFBQ45160X10 160 377.0 220 480
PVFBQ45180X10 180 424.0 240 540
PVFBQ45200X10 200 471.0 258 600
PVFBQ45225X10 225 530.0 281.5 675
PVFBQ45250X10 250 589.0 304 750
PVFBQ45280X10 280 660.0 332 840
PVFBQ45315X10 315 742.0 366.5 945
PVFBQ45355X10 355 837.0 400.5 1065
PVFBQ45400X10 400 842.0 436 1200
PVFBQ45500X10 500 1178 523 1520
Note :
• All dimensions are in mm
• All fabricated fittings are available in different pressure classes up to PN 20 kg/cm2 as per ISO : 1452. Fittings in other standard and not covered above are also made available on request.
