PVC Quick-Fix Double Socket Bend 30°

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: 63mm to 500mm in different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

Code D Y
L R
PVFBQ30063x10 63 99 240 189
PVFBQ30075x10 75 118 246 225
PVFBQ30090x10 90 142 266 270
PVFBQ30110x10 110 173 270 330
PVFBQ30140x10 140 220 316 420
PVFBQ30160x10 160 252 316 480
PVFBQ30180x10 180 283 346 540
PVFBQ30200x10 200 314 370 600
PVFBQ3022510 225 354 390 675
PVFBQ30280x10 280 440 450 840
PVFBQ30315x10 315 495 450 945
PVFBQ30355x10 355 558 460 1065
PVFBQ30400x10 400 628 500 1200

Note :
• All dimensions are in mm.
• All fabricated fittings are available in 10 kg/cm² pressure rating. Please specify other pressure ratings as per the requirement viz. 04, 06, 08, 12.5 kg/cm²
• Other fittings / sizes are available on demand.
