HDPE BLIND FLANGE

All Products..

PE Pipes

download pdf file

HDPE BLIND FLANGE

Technical Specifications

Size ID OD PCD HOle Thickness t
Number Diameter
20 95 67 4 17 20
25 102 73 4 17 20
32 114 83 4 17 20
40 121 87 4 17 20
50 133 98 4 17 20
63 152 114 4 20 20
75 165 127 4 20 20
90 184 146 4 20 20
110 216 178 4 20 20
125 254 210 8 20 20
140 254 210 8 20 20
160 279 235 8 20 20
180 305 260 8 20 20
200 337 292 8 20 25
225 368 324 8 20 25
250 406 356 8 22 30
280 406 356 8 22 30
315 457 406 12 22 30
355 527 470 12 25 30
400 578 521 12 25 30
450 641 584 12 25 30
500 705 641 16 25 30
560 762 699 16 29 30
630 826 756 16 29 30
710 895 840 24 31 58
800 1015 950 24 34 60
900 1115 1050 28 34 65
1000 1230 1160 28 37 70
1200 1455 1380 32 40 80
1400 1685 1590 36 49 80
1600 1800 1710 40 43 90
