ECCENTRIC REDUCER SINGLE STAGE

Technical Specifications

φD φd L1 L2 Z
25 20 18 15 50
32 20 18 15 50
32 25 18 15 50
40 20 18 15 60
40 25 18 15 60
40 32 18 15 60
50 25 18 15 65
50 32 18 15 65
50 40 18 15 65
63 32 18 15 70
63 40 18 15 70
63 50 18 15 70
75 40 19 15 70
75 50 19 15 70
75 63 19 16 70
90 50 24 15 80
90 63 24 16 80
90 75 24 21 80
110 63 30 18 95
110 75 30 21 95
110 90 30 24 95
125 75 34 21 105
125 90 34 24 105
125 110 34 30 105
140 90 37 24 115
140 110 37 30 115
140 125 37 34 115
160 110 42 30 125
160 125 42 34 125
160 140 42 37 125
180 125 47 34 135
180 140 47 37 135
180 160 47 42 135
200 140 52 37 140
200 160 52 42 140
200 180 52 47 140
225 160 57 42 165
225 180 57 47 165
225 200 57 52 165
250 180 62 47 180
250 200 62 52 180
250 225 62 57 180
280 200 72 52 205
280 225 72 57 205
280 250 72 62 205
315 225 82 57 230
315 250 82 62 230
315 280 82 72 230
