CLAMP SERVICE SADDLE (WITH REINFORCED RING)

All Products..

PE Pipes

download pdf file

CLAMP SERVICE SADDLE (WITH REINFORCED RING)

Technical Specifications

Code Size (mm x inch) -D Size (mm x inch) -C A E NO of Bolt
20 ½” 60.8 M6x30 2
25 ½”,¾” 70.8 M6x30 2
32 ½”, ¾”, 1” 80.0 M8x45 2
40 ½”, ¾”, 1” 81.0 M8x45 2
50 ½”, ¾”, 1”, 1¼” 98.0 M8x45 4
63 ½”, ¾”, 1”, 1¼”, 1½” 115.0 M8x45 4
75 ½”, ¾”, 1”, 1¼”, 1½”, 2 127.1 M8x45 4
90 ½”, ¾”, 1”, 1¼”, 1½”, 2 145.0 M8x55 4
110 ½”, ¾”, 1”, 1¼”, 1½”, 2 174.5 M8x55 4
