502-H
502-H
Specification
-
Flow Rates (lph): 226 to 345
-
Working Pressure (kg/cm²): 1.5 to 3.5
-
Wetted Diameter (m): 13.0 to 17.0
Applications
- Overhead irrigation for extra-range spacings upto 10x10 m
- Can also be used for under tree irrigation.
- Recommended for vegetables & nurseries, etc.
Features & Benefits
 |
 |
Corrugated Jet Spreader Corrugated jet spreader for uniform distribution and fine water droplets for delicate irrigation of all crops |
Unique Turbo Hammer Unique turbo hammer for uniform rotation. |
 |
 |
Specially Designed Nozzle Unique design of nozzle ensures longer throw |
Threaded Inlet Connection Available in 1/2" male threaded connections. |
 |
 |
Neck Spring Protection Cover Additional cover provided for neck spring protection |
Easy to Assemble & Dismantle For easy maintenance & inspection |
