5024 4 sprinkler


  • Flow Rates (lph): 175 to 490

  • Working Pressure (kg/cm²): 1.5 to 4.0

  • Wetted Diameter (m): 12.0 to 21.0


  • These sprinklers are specially used for undertree application.
  • Can also be used in nurseries and greenhouses.
  • Suitable to use with Jain Rainport Systems.

Features & Benefits

Unique Hammer
Tringular solid special diffuser provided for uniform distribution.
Red Cap for Protection
Plastic protection cap protects spring from sand and gives longer life to sprinkler.
Heavy Duty Retraction Spring
Heavy duty stainless steel fulcrum pin and strong and reliable SS spring
Innovative Bayonet Nozzle Design
Integrated stream straightening vanes in nozzles for maximum throw
High Performance Washer
Long life Teflon washer helps to give uniform & hassle free rotation
Threaded Inlet Connection
For connectivity with assembly 1/2" male threaded inlet connection is available
