5022 UNI


  • Discharges (lph): 440-800

  • Diameter (m): 16 to 23

  • Recommended Pressure (kg/cm2): 1.5 to 4


  • Suitable to use with Jain Rainport Systems.
  • Recommended for closely spaced field crops, such as potato, leafy vegetables, cotton, oil seeds, pulses, cereals and fodder crops.
  • Irrigation and germination of vegetables, flowers and nursery crops.

Features & Benefits

Patented Super Diffuser Plate with Slotted Arm
Innovative hammer with SD (super- diffuser) plate design with slotted arm for uniform distribution

Low Pressure Operating Sprinkler
Specially designed stainless steel spring to work at lower pressure (1.5 kg/cm2)

Heavy Duty Retraction Spring
Heavy duty stainless steel fulcrum pin and heavy duty SS spring

Innovative Bayonet Nozzle Design
Colour coded bayonet nozzles with integrated stream straightening vanes in nozzles for maximum throw

High Performance Washer Long life Teflon washer helps
to give uniform & hassle free rotation, with less wear and tear

Red Cap for Protection
Plastic protection cap protects the spring from sand and gives longer life to sprinkler
