5022 SD-U


  • Flow Rates (lph):310 to 800

  • Working Pressure (kg/cm²):1.5 to 4.0

  • Wetted Diameter (m): 18.0 to 23.0


  • Suitable to use with Jain Rainport Systems.
  • Recommended for closely spaced field crops, such as potato, leafy vegetables, cotton, oil seeds, pulses, cereals and fodder crops.
  • Irrigation and germination of vegetables, flowers and nursery crops.

Features & Benefits

Patented Super Diffuser Plate
Innovative hammer with SD (super-diffuser) plate design for uniform distribution
Low Pressure Operating Sprinkler
Specially designed stainless steel spring to work at lower pressure (1.5 kg/cm2)
Heavy Duty Retraction Spring
Heavy duty stainless steel fulcrum pin and heavy duty SS spring
Innovative Bayonet Nozzle Design
Colour coded bayonet nozzles with integrated stream straightening vanes in nozzles for maximum throw
High Performance Washer
Long life Teflon washer helps to give uniform & hassle free rotation, with less wear and tear
Red Cap for Protection
Plastic protection cap protects the spring from sand and gives longer life to sprinkler
