5022 - 4 Sprinkler


  • Flow Rates (lph) : 235 to 630

  • Working Pressure (kg/cm²): 1.0 to 3.0

  • Wetted Diameter (m): 18.0 to 23.0


  • Recommended for closely spaced field crops, such as potato, leafy vegetables, cotton, oil seeds, pulses, cereals and fodder crops.
  • Irrigation and germination of vegetables, flowers and nursery crops.
  • Suitable to use with Jain Rainport Systems.

Features & Benefits

Unique Hammer
Triangular wedge drive mechanism for uniform water distribution.
Red Cap for Protection
Plastic protection cap protects spring from sand and gives longer life to sprinkler
Heavy Duty Retraction Spring
Heavy duty stainless steel fulcrum pin and strong and reliable SS spring.
Innovative Bayonet Nozzle Design
Colour coded bayonet nozzles with integrated stream straightening vanes in nozzles for maximum throw.
High Performance Washer
Long life Teflon washer helps to give uniform & hassle free rotation.
Low Pressure Operating Sprinkler
Specially designed stainless spring to work at lower pressure (1.0 kg/cm2).
