Jain Super Flow - Bronze
Jain Super Flow - Bronze
Specification
-
Sizes (inch): 2, 2.5, 3.0
-
Nominal flow rate(m³/hr): 20, 25, 30, 40, 50
-
Max. working pressure(bar) : 6
Features & Benefits
- Smart Clean Element Slotted, ribbed cartridge maintains water flow even during partial screen clogging, ensuring low pressure drop and longer cleaning intervals.
- Robust Twill-Weave Screen Twill-weave stainless steel screen provides high strength and withstands coarse particles and debris
- High Filtration Area A large filtration area increases dirt-holding capacity and helps extend the interval between element cleaning, reducing maintenance frequency.
- Low Pressure Drop Optimized internal flow path and large filtration area ensure low pressure loss across a clean filter, helping reduce pumping energy requirements.
- Excellent Corrosion & Chemical Resistance Engineering polymer construction offers excellent resistance to corrosion and to commonly used agricultural chemicals and fertilizers, providing dependable service under irrigation conditions.
- User-Friendly Polymer Clamp High-strength engineering polymer clamp provides secure closure while allowing smooth and convenient opening for routine filter inspection and cleaning.
- Multiple Connection Options Available with 2", 2½" and 3" BSP/NPT male threaded connections. Flanged and grooved connection options are also available to suit different installation requirements.
- Choice of Filtration Degrees Available in 80, 100, 125, 200 and 300 micron filtration options to suit different irrigation water quality and application requirements.
- Designed for 6 Bar Working Pressure Robust construction enables operation at a maximum working pressure of 6 bar (87 psi), making Super Flow Bronze suitable for a wide range of agricultural filtration applications
