Service Saddle Threaded 2 Way

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: Different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE
SIZE T L H
(MM) X INCH (BSP) (MM) (MM)
TSS032012 32X ½ ½ 64.0 73.4
TSS032034 32X ¾ ¾ 64.0 75.4
TSS040012 40X ½ ½ 85.0 86.0
TSS040034 40X ¾ ¾ 85.0 85.0
TSS050012 50x ½ ½ 90.0 106.0
TSS050034 50x ¾ ¾ 90.0 106.0
TSS050100 50x 1 1 90.0 107.0
TSS063012 63X ½ ½ 105.0 110.0
TSS063034 63X ¾ ¾ 105.0 111 .0
TSS063100 63X 1 1 105.0 115.0
TSS075012 75X ½ ½ 116.0 127.0
TSS075034 75X ¾ ¾ 116.0 127.0
TSS075100 75X 1 1 116.0 127.0
TSS090012 90X ½ ½ 135.0 1 38.0
TSS090034 90X ¾ ¾ 1 35.0 140.0
TSS090100 90X 1 1 135.0 142.0
TSS110012 110x ½ ½ 154.0 158.0
TSS110034 110X ¾ ¾ 154.0 159.0
TSS110100 110x 1 1 154.0 162.0
TSS125012 125X ½ ½ 173.0 183.0
TSS125034 125X ¾ ¾ 173.0 183.0
TSS125100 125X 1 1 173.0 187.0
TSS140012 140X ½ ½ 188.0 182.0
TSS140034 140X ¾ ¾ 188.0 184.0
TSS140100 140X 1 1 188.0 190.0
TSS140114 140X 1 ¼ 1 ¼ 1 88.0 197.0
TSS140112 140X 1½ 1 ½ 188.0 197.0
TSS160012 160X ½ ½ 212.0 204.0
TSS160034 160X ¾ ¾ 212.0 208.0
TSS160100 160X 1 1 212.0 214.0
TSS160114 160X 1 ¼ 1 ¼ 212.0 218.0
TSS160112 160X 1½ 1 ½ 212.0 218.0
TSS160200 160X 2 2 212.0 226.0
Note: The molded fittings are available in different pressure. classes up to PN 16 kg/cm2 as per ISO : 1452. Fittings in other standard and not covered above are also made available on request.
