Equal Tee

  • Product Standard: As Per IS 10124, IS 7834, DIN 8063, ISO 1452 and company standard

  • Range: Different pressure ratings ranging from PN 4 to PN 16 kg/cm2

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE
SIZE (MM)
D (MM)
S (MM)
C (MM)
L MAX.
MIN. MAX
MT020 20 20.1 20.3 16 27.5 55
MT025 25 25.1 25.3 19 33 66
MT032 32 32.1 32.3 22 39 78
MT040 40 40.1 40.3 26 47 94
MT050 50 50.1 50.3 31 57 113.5
MT063 63 63.1 63.3 38 72 143.5
MT075 75 75.1 75.3 44 84 168
MT090 90 90.1 90.3 51 100 200
MT110 110 110.1 110.4 61 118 236
MT125 125 125.1 125.4 68 133 266
MT140 140 140.1 140.5 76 145 298
MT160 160 160.2 160.5 86 165 335
MT16010 160 160.2 160.5 86 167.5 335
MT180 180 180.2 180.5 86 180 376
MT200 200 200.3 200.6 106 208.5 417
MT20010 200 200.3 200.6 106 208.5 417
Note: The molded fittings are available in different pressure. classes up to PN 16 kg/cm2 as per ISO : 1452. Fittings in other standard and not covered above are also made available on request.
