PVC Moulded Stub End (Flange Adaptor)

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE
SIZE (MM)
D (MM) D1 D2 S L
MIN. MAX (MM) (MM) (MM) (MM)
PPSE063PN16 63 63.1 63.3 76.5 90.5 38.0 42.1
PPSE075PN16 75 75.1 75.3 89.7 106.0 44.0 48.5
PPSE090PN16 90 90.1 90.3 107.1 124.7 51.0 56.5
PPSE110PN16 110 110.1 110.4 129.5 149.8 61.0 66.5
PPSE125PN16 125 125.1 125.4 146.0 168.5 69.0 75.0
PPSE140PN16 140 140.1 140.4 164.1 189.0 76.0 85.5
PPSE160PN16 160 160.1 160.5 185.0 213.5 86.0 92.4
PPSE200PN16 200 200.1 200.5 230.1 255.0 106.0 115.0
Note: The molded fittings are available in different pressure. classes up to PN 16 kg/cm2 as per ISO : 1452. Fittings in other standard and not covered above are also made available on request.
