Flange - Universal

We at Jains, believe in supplying the system rather than individual products. Its very easy to produce and supply the pipes, but supply of matching fittings is very critical. We manufacture and supply a wide variety of PVC fittings to suit the final application requirement. Apart from standard products, We also manufacture and supply a wide range of special, application specific developed fittings as per company standard or customer specifications to fulfil the end application requirements. The fittings are either injection moulded or fabricated from the pipes. PVC Fittings are manufactured as per the guidelines set by the company apart from referring to the national and international standards.


Technical Specifications

CODE SIZE (MM) D (MM) D1 (MM) PCD (MM) HOLE DIA. NO.OF HOLES L (MM)
PPFM50ISOPN16 50 63.8 152.9 110 18 4 18
PPFM63ISOPN16 63 79.8 165.6 125.5 18.0 4.0 18.0
PPFM75ISOPN16 75 94.3 185.5 145.0 18.0 4.0 19.0
PPFM90ISOPN16 90 111.9 200.9 160.0 18.0 8.0 20.5
PPFM110ISOPN16 110 135 220.5 180.0 18.0 8.0 22.0
PPFM125ISOPN16 125 150.5 230.3 190.0 18.0 8.0 24.0
PPFM140ISOPN16 140 168.8 250.0 210.0 18.0 8.0 25.7
PPFM160ISOPN16 160 192.5 285.5 240.1 22.0 8.0 28.0
PPFM200ISOPN16 200 240.7 342.0 298.8 24.0 8.0 31.0
