Tee 90° equal

Features & Benefits

  • PE 100 SDR 11 (ISO S5)
  • 10 bar Gas
  • 4 mm pin connectors
  • Limited path fusion indicators

Technical Specifications

d
[mm]
Code Wt
[kg]
d1
[mm]
L
[mm]
L1
[mm]
z
[mm]
z1
[mm]
H
[mm]
75 753 211 612 0.569 97 178 54 35 143 87
90 753 201 813 0.891 115 205 62 41 161 94
110 753 201 814 1.576 140 255 72 56 184 104
125 753 201 815 2.212 161 276 78 60 207 113
160 753 201 817 4.386 196 325 92 71 206 103
180 753 201 818 6.796 225 344 90 82 250 110
