Tapping tee
Tapping tee
Features & Benefits
- PE 100 SDR 11 (ISO S5)
- 10 bar Gas
- With integrated cutter to tap live mains under pressure
- Long fusion outlet
- O-ring-sealed screw cap
- For ELGEF Plus Branch Saddle d63-225mm, pipe SDR 11
- For ELGEF Plus Branch Saddle d90-315mm, pipe SDR 17
- *For ELGEF Plus Branch Saddle d250-315mm, pipe SDR 11 and d250-400mm, pipe SDR 17
- *For ELGEF Plus Branch Saddle d110-225mm, pipe SDR11 and d110-315mm, pipe SDR17
Technical Specifications
| d [mm] |
d1 [mm] |
Code | Wt [kg] |
d2 [mm] |
L [mm] |
z [mm] |
SW [mm] |
|
| 63 | 20 | 193 280 358 | 0.380 | 32 | 69 | 130 | 17 | |
| 63 | 25 | 193 280 359 | 0.375 | 32 | 70 | 130 | 17 | |
| 63 | 32 | 193 280 184 | 0.377 | 32 | 76 | 130 | 17 | |
| 63 | 40 | 193 280 360 | 0.396 | 32 | 81 | 137 | 17 | |
| 63 | 63 | 193 280 185 | 1.099 | 32 | 100 | 160 | 17 | |
| * | 63 | 63 | 193 280 711 | 1.120 | 35 | 100 | 160 | 17 |
| ** | 63 | 63 | 193 280 290 | 1.086 | 41 | 100 | 160 | 17 |
