Tapping Saddle Monobloc

Features & Benefits

  • PE 100 SDR 11 (ISO S5)

  • 10 bar Gas
  • With integrated cutter to tap live mains under pressure
  • Delivery without lower part for assembling as Topload with tool no. 799 301 558
  • 4 mm pin connectors
  • Fusion indicator
  • Long fusion doutlet
  • O-ring-sealed screw cap

Technical Specifications

d
[mm]
d1
[mm]
Code Wt
[kg]
d2
[mm]
H
[mm]
H1
[mm]
L
[mm]
L1
[mm]
z
[mm]
32 20 193 281 459 0.156 12 83 29 101 65 90
