Stop-off Saddle with PE-adaptor Maximum passage 50 mm
Stop-off Saddle with PE-adaptor Maximum passage 50 mm
Features & Benefits
- PE 100 SDR 11 (ISO S5)
- 10 bar Gas
- Complete with lower part
- Supplied as Kit with PE-Stop-Off Adaptor
- PE Stop-Off insert
- 4 mm pin connectors
- Limited path fusion indicators
- *Delivery without lower part for assembling as Top Load with tool no. 799.350.477; angle adaptor (799.350.340) for fusion cable required
Technical Specifications
| d [mm] |
G ["] |
Code | Wt [kg] |
L [mm] |
|
| 63 | 2¾ | 193 149 237 | 0.606 | 165 | |
| 75 | 2¾ | 193 149 247 | 0.765 | 165 | |
| 90 | 2¾ | 193 149 257 | 0.696 | 165 | |
| 110 | 2¾ | 193 149 267 | 0.732 | 165 | |
| 125 | 2¾ | 193 149 277 | 0.785 | 165 | |
| 140 | 2¾ | 193 149 287 | 0.820 | 165 | |
| 160 | 2¾ | 193 149 297 | 0.772 | 165 | |
| 180 | 2¾ | 193 149 307 | 0.920 | 165 | |
| 200 | 2¾ | 193 149 317 | 0.913 | 165 | |
| 225 | 2¾ | 193 149 327 | 0.910 | 165 | |
| 250 | 2¾ | 193 149 337 | 0.936 | 165 | |
| * | 280 | 2¾ | 193 149 347 | 0.920 | 165 |
| * | 315-355 | 2¾ | 193 149 357 | 0.660 | 165 |
| * | 400 | 2¾ | 193 149 377 | 0.920 | 165 |
