Stop-off Saddle (kit) Maximum passage 56.5 mm

Features & Benefits

  • PE 100 SDR 11 (ISO S5)
  • 10 bar Gas
  • Complete with lower part
  • Stop-Off insert (CW617N) and plug
  • 4 mm pin connectors
  • Limited path fusion indicators
  • Stop-Off insert with outside thread Rp 2 1/2” and internal thread Rp 2” suited for common tapping devices permitting “gas-tight” installation
  • *Delivery without lower part for assembling as Top Load with tool no. 799.350.475; angle adaptor (799.350.340) for fusion cable required
  • For main dimension d63 and d75mm we recommend a maximum cutting diameter of d = 39mm

Technical Specifications

d
[mm]
G
["]
Code Wt
[kg]
L
[mm]
63 193 149 437 1.770 165
75 193 149 447 1.900 165
90 193 149 457 1.775 165
110 193 149 467 1.788 165
125 193 149 477 1.923 165
140 193 149 487 1.945 165
160 193 149 497 1.861 165
180 193 149 507 2.017 165
200 193 149 517 2.092 165
225 193 149 527 2.031 165
250 193 149 537 2.058 165
* 280 193 149 547 1.550 165
* 315-355 193 149 557 1.770 165
* 400 193 149 577 1.550 165
