Elbow 45° -2

Features & Benefits

  • PE 100 SDR 11 (ISO S5)
  • 10 bar Gas
  • 4 mm pin connectors
  • Limited path fusion indicators
  • Two separate fusion zones

Technical Specifications

d
[mm]		 Code Wt
[kg]		 d1
[mm]		 L
[mm]		 L1
[mm]		 z
[mm]
200 753 151 819 7.566 250 232 104 128
225 753 151 820 11.300 280 247 112 135
250 753 151 821 13.500 310 275 123 152
