Branch Saddle outlet 90-125 mm

Features & Benefits

  • PE 100 SDR 11 (ISO S5)
  • 10 bar Gas
  • Branch Saddle complete, incl. lower part and 3 screws
  • Additional fixing with snatch hinge
  • Electrofusion outlet with integrated pipe fixation
  • Protected wire without medium contact
  • 4 mm pin connectors
  • Limited path fusion indicators
  • * Delivered without lower part. Pipe fixation with multiple use assembly tool no. 193.281.027

Technical Specifications

d [mm] d1[mm] Code Weight[kg] H[mm] L[mm] L1[mm] B[mm] d2[mm]
110 90 193 135 009 1.124 101 220 82 164 65
110 110 193 135 010 1.224 107 220 88 164 65
125 90 193 135 019 1.134 101 220 82 179 65
125 110 193 135 020 1.290 107 220 88 179 65
* 140 90 193 135 029 0.982 101 220 81 195 65
* 140 110 193 135 030 1.087 107 220 87 195 65
160 90 193 135 039 1.449 102 240 82 215 65
160 110 193 135 040 1.582 108 240 88 215 86
160 125 193 135 041 1.782 129 240 99 215 86
180 90 193 135 049 1.672 102 260 82 237 65
180 110 193 135 050 1.765 108 260 88 237 86
180 125 193 135 051 2.015 129 260 99 237 86
200 90 193 135 059 1.803 102 260 82 253 65
200 110 193 135 060 1.963 108 260 88 253 86
200 125 193 135 061 2.128 129 260 99 253 86
225 90 193 135 069 2.006 102 260 82 287 65
225 110 193 135 070 2.400 108 260 88 287 86
225 125 193 135 071 2.312 129 260 99 287 86
250 90 193 135 079 2.145 102 260 82 312 65
250 110 193 135 080 2.258 108 260 88 312 86
250 125 193 135 081 2.500 129 260 99 312 86
