EQUAL TEE
EQUAL TEE
Technical Specifications
| Size | Outer Diameter | Z1 | |
| min | max | ||
| 20 | 20.1 | 20.3 | 50 |
| 25 | 25.1 | 25.3 | 62 |
| 32 | 32.1 | 32.3 | 80 |
| 40 | 40.1 | 40.4 | 80 |
| 50 | 50.1 | 50.5 | 90 |
| 63 | 63.1 | 63.6 | 95 |
| 75 | 75.1 | 75.7 | 113 |
| 90 | 90.1 | 90.9 | 135 |
| 110 | 110.1 | 111.0 | 165 |
| 125 | 125.1 | 126.2 | 182 |
| 140 | 140.1 | 141.3 | 210 |
| 160 | 160.1 | 161.5 | 240 |
| 180 | 180.1 | 181.7 | 270 |
| 200 | 200.1 | 201.8 | 300 |
| 225 | 225.1 | 227.1 | 338 |
| 250 | 250.1 | 252.3 | 375 |
| 280 | 280.1 | 282.6 | 420 |
| 315 | 315.1 | 317.9 | 473 |
| 355 | 355.1 | 358.2 | 533 |
| 400 | 400.1 | 403.6 | 600 |
| 450 | 450.1 | 454.1 | 675 |
| 500 | 500.1 | 504.5 | 750 |
| 560 | 560.1 | 565.0 | 840 |
| 630 | 630.1 | 635.7 | 945 |
| 710 | 710.1 | 716.4 | 1065 |
| 800 | 800.1 | 807.2 | 1200 |
| 900 | 900.1 | 908.1 | 1350 |
| 1000 | 1000.1 | 1009.0 | 1500 |
| 1200 | 1200.1 | 1210.8 | 1800 |
| 1400 | 1400.1 | 1412.2 | 2100 |
| 1600 | 1600.1 | 1614.4 | 2400 |
| 2000 | 2000.1 | 2018.0 | 3000 |
| 2500 | 2500.1 | 2525.0 | 3750 |
