DUCK FOOT BEND
DUCK FOOT BEND
Technical Specifications
| Size | Min | Max | Z |
| 63 | 63.1 | 63.6 | 347 |
| 75 | 75.1 | 75.7 | 433 |
| 90 | 90.1 | 90.9 | 504 |
| 110 | 110.1 | 111.0 | 598 |
| 125 | 125.1 | 126.2 | 668 |
| 140 | 140.1 | 141.3 | 739 |
| 160 | 160.1 | 161.5 | 833 |
| 180 | 180.1 | 181.7 | 927 |
| 200 | 200.1 | 201.8 | 1041 |
| 225 | 225.1 | 227.1 | 1159 |
| 250 | 250.1 | 252.3 | 1277 |
| 280 | 280.1 | 282.6 | 1418 |
| 315 | 315.1 | 317.9 | 1583 |
| 355 | 355.1 | 358.2 | 1791 |
| 400 | 400.1 | 403.6 | 2003 |
| 450 | 450.1 | 454.1 | 2239 |
| 500 | 500.1 | 504.5 | 2475 |
| 560 | 560.1 | 565.0 | 2758 |
