  • Flow Rates (lph): 60 to 490

  • Working Pressure (kg/cm²): 1.5 to 3.5

  • Wetted Diameter (m): 9.0 to 17.0


  • Overhead irrigation for extra-range spacing’s up to 12 m
  • Recommended for closely spaced field crops, such as potato, leafy vegetables, cotton, oil seeds, pulses, cereals and fodder crops.

Features & Benefits

Low Angle Options Available
Optimum water distribution with 9°, 15° and 24° trajectories for a wide range of applications
Unique Swivel Design
Unique swivel for protection against snails
Silicon Motion Controller
Sprinkler with silicone motion controller improves performance
Specially Designed Side Ribs
Smooth streamlined side ribs to secure the swivel and give minimum obstructions to water jet
Detachable Nozzle & Swivel
Offers ease in maintenance & inspection
Threaded Inlet Connection
1/2" or 3/8" male threaded and female Acme thread connection available.
